Product Name:H5111 DOUBLE ROW BEET HARVEST MACHINE
-
Category:H4200 BEET HARVEST MACHINE
-
Main Category:BEET HARVEST MACHINE
TORUNOGLU TWO ROWS 5 TONS CAPACITY BEET HARVEST MACHINE
IT IS A DOUBLE ROW SUGAR BEET HARVESTER MACHINE THAT HAS CUTTING, DISJOINING, CLEANING, STORING AND UNLOADING FUNCTIONS. IT IS CONNECTED TO A TRACTORS TOW BAR. WITH ITS PUMPS (5 PCS) ATTACHED TO ITS REINFORCED TRANSMISSION,
IT PROVIDES A SPECIAL SOLUTION IN MUDDY FIELDS AND SEPARATES WEED FROM SUGAR BEET IT HAS BEEN IMPROVED FOR OPTIMUM PERFORMANCE IN MUDDY FIELDS THANKS TO ITS CLEANING ROLLERS AND MOVING ARMS PLACED IN BETWEEN LIFTERS.
IN OUR H5111 MODEL, THE TANK ELEVATION ARMS ARE DESIGNED IN PARALLEL AND THE TANK REACH A DISCHARGE HEIGHT OF 420 CM, WHILE THE ANGLE IT MAKES WITH THE GROUND DOES NOT EXCEED 30 DEGREES, THUS THE TANK CAN BE EMPTIED
MORE QUICKLY. ALSO, OUR H5111 MODEL HAS DOUBLE PUMPS TO UNLOAD THE TANK FASTER AND MORE EFFICIENTLY. THE OIL RESERVOIR OF THE HYDRAULIC SYSTEM IS INSTALLED TO THE MACHINE AND USES 46 HYDRAULIC OIL. THANKS TO ITS ROW CONTROL
ABILITY (ROW TRACKING SYSTEM), HARVESTING ROW GAP AND DEPTH SETTINGS ARE FULLY AUTOMATIC. A SPECIALLY DESIGNED TWIN WHEEL SYSTEM IS USED TO REDUCE THE WASTAGE DURING THE FIRST HARVESTING IN THE FIELD.
TECHNICIAL SPECIFICATIONS
Uzunluk (cm) |
Length (cm) |
650 |
Genişlik (cm) |
Width (cm) |
395 |
Yükseklik |
Height (cm) |
373 |
Ağırlık (Kg) |
Weight (Kg) |
4600 |
Güç (HP) |
Power (Hp) |
100-120 |
Lastik Çapı |
Tire Diameter |
380/85X24-210/95X32 |
Kuyruk Mili Devri |
Power Take Off rom (d/d) |
540 |
Yükleme yüksekliği (cm) |
Loading Height (cm) |
420 |
İş Kapasitesi (d/h) |
Operational Capacity (d/h) |
3 |
Depo Kapasitesi (Kg) |
Storage Capacity (Kg) |
5000 |
Depo Boşaltma Tipi |
Container Discharge Type |
Bantlı / Belted |
![](/upload/Images/image/%C3%87%C4%B0FT%20SIRA%20HAZIRLAYICI.jpg)
![](/upload/Images/image/%C3%87%C4%B0FT%20SIRA%20KRANK.jpg)
![](/upload/Images/image/%C3%87%C4%B0FT%20SIRA%20POMPA.jpg)
